Showing 1–9 of 64 results

Low Voltage LVS (Offgrid)

Rated 0 out of 5
BATTERY-BOX PREMIUM LVS One Battery-Box Premium LVS is a lithium iron phosphate (LFP) battery pack for use with an external inverter. A Battery-Box Premium LVS contains between 1 to 6 battery modules LVS stacked in parallel and can reach 4 to 24 kWh usable capacity. Connect up to 16 Battery-Box LVS 16.0 in parallel for a maximum size of 256 kWh. Ability to scale by adding LVS modules or parallel towers of 1 to 4 modules later. Download Datasheet

Low Voltage LVL (Offgrid)

Rated 0 out of 5
The BYD Battery-Box Premium LVL is a lithium iron phosphate (LFP) battery for use with an external inverter. Thanks to its control and communication port (BMU), the Battery-Box Premium LVL scales to meet the project requirements, no matter how large they may be. Start with Battery-Box Premium LVL15.4 (15.4 kWh) and extend anytime to 983 kWh using parallel interconnection of up to 64 batteries. Two LVL batteries can be stacked in top of each other. Download Datasheet

Low Voltage LVS (Ongrid)

Rated 0 out of 5
BATTERY-BOX PREMIUM LVS One Battery-Box Premium LVS is a lithium iron phosphate (LFP) battery pack for use with an external inverter. A Battery-Box Premium LVS contains between 1 to 6 battery modules LVS stacked in parallel and can reach 4 to 24 kWh usable capacity. Connect up to 16 Battery-Box LVS 16.0 in parallel for a maximum size of 256 kWh. Ability to scale by adding LVS modules or parallel towers of 1 to 4 modules later. Download Datasheet

HIGH VOLTAGE HVS / HVM (Ongrid)

Rated 0 out of 5
Battery Box Premium HVS One Battery-Box Premium HVS is composed of 2 to 5 HVS battery modules that are connected in series to achieve a usable capacity of 5.1 to 12.8 kWh. Additionally, direct parallel connection of up to 3 identical Battery-Box Premium HVS allows a maximum capacity of 38.4 kWh. Ability to scale by adding HVS modules or parallel HVS stacks later. Battery Box Premium HVM One Battery-Box Premium HVM is composed of 3 to 8 B-Plus HVM 2.71 battery modules that are serially connected to achieve a usable capacity of 8.1 to 21.7 kWh. Additionally, direct parallel connection of up to 3 identical Battery-Box Premium HVM allows a maximum capacity of 65.0 kWh. Ability to scale by adding HVM modules or parallel HVM stacks at anytime. Download Datasheet

LOW VOLTAGE LVL (Ongrid)

Rated 0 out of 5
The BYD Battery-Box Premium LVL is a lithium iron phosphate (LFP) battery for use with an external inverter. Thanks to its control and communication port (BMU), the Battery-Box Premium LVL scales to meet the project requirements, no matter how large they may be. Start with Battery-Box Premium LVL15.4 (15.4 kWh) and extend anytime to 983 kWh using parallel interconnection of up to 64 batteries. Two LVL batteries can be stacked in top of each other. Download Datasheet

CLOUD CONNECT ADVANCED (CCA)

Rated 0 out of 5
Description One of the smallest solar data loggers on the planet, Tigo’s Cloud Connect Advanced (CCA) enables valuable insight into module level performance data. It is the hub for data from Tigo’s O, S and M products and customers can also connect their inverters, batteries, building meters, and more. Real-time and historical data from the CCA can be viewed in the Tigo Energy Intelligence platform. The CCA is available as an add on kit, or integrated with inverters. It is supported by all major string inverter and module manufacturers worldwide. Functions
  • Universal data-logger that works with the TAP, TS4-A-O, TS4-A-S, and TS4-A-M
Features and benefits
  • Works with Tigo TS4-O,M,S
  • Enables module level monitoring with the Tigo Energy intelligence platform when paired with the TAP
  • Provides immediate access to system data for installers
  • Enables internet connection via Ethernet, Wi-Fi or optional cellular connectivity
  • The Indoor Kit includes a CCA and a TAP (see downloads)
  • The Outdoor Kit includes a CCA, a TAP, and an IP68-rated outdoor enclosure (see downloads)

RSS SIGNAL DETECTOR

Rated 0 out of 5
Tester for PLC Rapid Shutdown Signal Tigo’s RSS Signal Detector is a functionality testing device for sensing the power line communication (PLC) signal from the Tigo RSS Transmitter to the TS4-F or TS4-R-F (Fire Safety) units. The Detector is used during installation to verify that the TS4-F units are receiving the keep-alive signal from the Transmitter. This is the handheld, failsafe tool to confirm that your PV system is compliant with NEC 2017 690.12 rapid shutdown specifications. Download Datasheet

RSS TRANSMITTER

Rated 0 out of 5
Description Tigo’s RSS (Rapid Shutdown System) Transmitter completes the cost-effective rapid shutdown system architecture when paired with Tigo’s UL-certified Fire Safety solutions – including the TS4-A-F (add-on), TS4-A-2F (add-on for two modules). The RSS Transmitter sends a signal to the TS4-F units to keep PV modules connected while powered on and supplying energy. TS4-F units automatically enter rapid shutdown mode when the RSS Transmitter is switched off and resume energy production when power is restored to the RSS Transmitter. This solution complies with NEC 2014, 2017, and 2020 690.12 rapid shutdown specifications utilizing power-line communication (PLC). Available as a Kit, DIN Rail, or PCBA for integration into inverters. Functions
  • Rapid shutdown initiation device for Tigo TS4-A-F and TS4-A-2F
Features and benefits
  • Multivendor UL Certified solution to meet the NEC 690.12 2017/2020 code requirements
  • Module-level deactivation with automatic or manual shutdown
  • Easy installation, no commissioning process is required
  • Compatible with the largest network of UL-listed residential & commercial inverters
  • Integrated into many inverters, enabling plug and play installations with Tigo TS4-A-F and TS4-A-2F
Download Datasheet - Commercial

TS4-A-2F

Rated 0 out of 5
Description The Tigo TS4-A-2F is a reliable, cost effective rapid shutdown solution that meets the latest module level shutdown requirements, including NEC 2017/2020. The TS4-A-2F is both IEC and UL certified for global acceptance. It is UL PVRSS certified for connectivity with the largest network of inverters, many of which have a built in RSS transmitter. By connecting to two modules, the TS4-A-2F reduces labor time and enables 16% fewer connections on a 14 panel string compared to single channel MLPE. Functions
  • Rapid Shutdown
Features and benefits
  • Single MLPE connects to 2 PV modules
  • IEC and UL certified
  • Meets US NEC rapid shutdown safety requirements
  • UL PVRSS certified with the largest network of inverters
  • 1000W (500W per channel)
  • 16-90V, 15A (per channel)
  • MC4 (standard) connectors
  • Snaps to module frame for easy mounting
  • Does not require ground wire
  • PLC communication
Configuration
  • 2 modules per TS4
Required
  • RSS Transmitter
Download Datasheet
