TS4-A-S

One system. Many options. For your individual needs. In combination with the Sunny Portal powered by ennexOS, the Data Manager M enables monitoring, management and gridcompliant power control in decentralized PV systems. Thanks to flexible expansion options, the Data Manager M is already well-equipped for business models in the energy market of the future. Whether as a cost-effective Lite variant for smaller systems with up to five devices and 30 kVA, or as an expanded solution for up to 50 devices and 2.5 MVA — the Data Manager is the ideal professional system interface for electric utility companies, direct sellers, service technicians and PV system operators. Coordinated user interfaces and intuitive assistance functions simplify operation, parameterization and commissioning. Both variants are modularly expandable with many additional functions and interfaces. ALL BENEFITS AT A GLANCE

• Quick and easy
• Easy integration of devices
• Centralized commissioning of all integrated components

Functional

• Complies with international grid integration requirements
• Combine storage systems, energy generators and e-mobility

Future-proof and flexible

• Flexibly expandable anytime
• Access to the energy market of the future based on ennexOS

Reliable and convenient

• Remote monitoring and parameterization possible
• Detailed analytics, error messages and reporting through Sunny Portal

Download Datasheet

Easy upgrade Easy integration of RS485 systems into the high-performance SMA Speedwire data communication The good news for all owners of PV systems with RS485 data communication is that with the SMA Com Gateway, even existing systems can benefit from all options of the modern SMA Speedwire data communication. Whether it’s a system upgrade or expansion, the SMA Com Gateway allows the use of the SMA Data Manager or the SMA Cluster Controller and thus integration of current and future system monitoring and system control solutions, such as commercial energy management. The PV system’s investment security is therefore guaranteed. Download Datasheet

Description Optimization is a Flex MLPE function available as an integrated modular junction box base (TS4-O) or as an add-on unit (TS4-A-O). Design using unequal string lengths, mixed orientations, or areas of mismatch. Install in shaded areas with a reduced setback ratio. In addition to optimization, the TS4-A-O enables module level monitoring, and rapid shutdown in compliance with NEC 2014, 2017, 2020. Functions

• Optimization
• Monitoring
• Rapid Shutdown

Features and benefits

• Suitable for up to 700W solar modules
• The higher performance optimizer with Predictive IV Technology (PIV)
• The ONLY optimizer with selective deployment
• Includes the benefits of Safety & Monitoring
• Meets US NEC rapid shutdown requirements
• Optimizes right out of the box
• Shade and age tolerance to maximize lifetime yield
• Works wirelessly with the TAP & CCA

Configuration

• 1 module per TS4

Required

• CCA + TAP

Download Datasheet

Description The Tigo TS4-A-2F is a reliable, cost effective rapid shutdown solution that meets the latest module level shutdown requirements, including NEC 2017/2020. The TS4-A-2F is both IEC and UL certified for global acceptance. It is UL PVRSS certified for connectivity with the largest network of inverters, many of which have a built in RSS transmitter. By connecting to two modules, the TS4-A-2F reduces labor time and enables 16% fewer connections on a 14 panel string compared to single channel MLPE. Functions

• Rapid Shutdown

Features and benefits

• Single MLPE connects to 2 PV modules
• IEC and UL certified
• Meets US NEC rapid shutdown safety requirements
• UL PVRSS certified with the largest network of inverters
• 1000W (500W per channel)
• 16-90V, 15A (per channel)
• MC4 (standard) connectors
• Snaps to module frame for easy mounting
• Does not require ground wire
• PLC communication

Configuration

• 2 modules per TS4

Required

• RSS Transmitter

Download Datasheet
